Expo-Light Screen Printing Screen Exposure Unit


THE LAWSON EXPO-LIGHT
Model 3248 (Shown with Optional Floor Legs)

 Click on picture to enlarge

Expo-Light 3248The Lawson Expo Light is a completely self contained screen printing exposure unit. It is shipped fully assembled, ready to use, with the entire light source and vacuum system safely contained within the main housing. Its compact enough to be easily moved anywhere and uses standard 120-volt, plug-in wiring.

The Lawson Expo-Light is fast, consistent and reliable. Lawson's exclusive instant vacuum draw-down provides positive film-to-screen contact for high resolution exposure. This is a feature that cannot be duplicated without a vacuum. In addition, the Expo-Light's dynamically balanced and focused-beam fluorescent tube system helps ensure good, clean stencil definition, screen after screen.

Model 2424To add versatility, the Expo-Light can also be used as a light table. Simply place a durable, high-density piece of translucent fiberglass over the glass exposure surface, flip a switch, and you now have two machines in one!

If your new to the screen-making world, don't worry! The Expo-Light exposure unit comes with a complete instruction manual/user guide, is easy to set up, use and maintain.

Standard Features
  • Easy-to-Use Control Panel
  • 1-1/4-Horsepower Vacuum
  • Adjustable Screen Exposure       Timer
  • Automatic Exposure and             Vacuum Shut-Off Feature
  • Dynamically Balanced               Tubes/Bulbs
  • Focused Light Rays
  • Exposure Calculator Printed      on Control Panel
  • Even Light Distribution
  • Instant Vacuum Draw and      Release
  • Gas Power Lifter on Vacuum      Top
  • Light Table Mode Setting
  • Instant-Start Fluorescent      Tubes
  • Non-Reflective Vacuum      Blanket
  • Heavy-Duty, Rubber-Flex       Vacuum Blanket
  • Bench Model Design
  • 120-Volt, Standard Plug-In      Wiring
  • Shipped Fully Assembled
  • One-Year Parts Warranty      (Excludes Blanket & Glass)

    Dimensions
    #2424: 37" wide x 28" deep
    #3248: 61" wide x 37" deep
    Note: allow an additional 4" for hose swing at rear of unit.

  • REASONS TO BUY A LAWSON EXPO-LIGHT
    1. Film-To-Screen Contact:
      Increase resolution and minimize distortion because of poor film contact.
    2. Focused Tube Exposure System:
      Enhances screen resolution, minimizes sawtoothing and decreases exposure time.
    3. Economically Priced:
      Competitive pricing for the budget-minded.

      Standard Sizes:
      • 24" x 24" 32" x 48"
      • 48" x 72"
    OPTIONAL FEATURES
    • Digital Timer
    • Floor Stand
    • Shelves
    • Wheels
    • Blacklights
    • Spare bulbs
    • Frames
    • Parahex Louver Grid
    • Export Electrics

    Copyrights 1995-2008 All Rights Reserved
    Lawson Screen & Digital Products, Inc.
    CALL TODAY: 1-800-325-8317
    Price and Design Subject to Change Without Notice
