Mini-Star Infrared Conveyor Dryer

Mini Star Dryers

The Lawson Mini-Star is a compact, lightweight, portable, easy-to- use dryer that is ideal for slower production runs, event site printing, schools, lab and prototype testing or the serious hobbyist. It operates on 115-volt, plug-in wiring or you can choose optional industrial 220-volt wiring. It can be moved anywhere or loaded into a minivan and it sets up in minutes. As with all Lawson equipment, the Mini-Star is part of Lawson's unique Trade-In, Trade-Up program, so you never have to worry about out-growing your dryer. This unit will provide the professional results your customers demand with both convenience and affordability.

Request A Quote

Standard Features

  • Bench Model Design
  • 18" belt width
  • 3'-long heat chamber
  • 5' overall length
  • 1' in-feed
  • 1' out-feed
  • Adjustable temperature control
  • Adjustable belt speed
  • Color blind infrared panel (18" x 18")
  • Direct drive conveyor system
  • Easy belt tracking
  • Anti drag belt support
  • Heat-reflective S & S memory belt
  • Reflective infrared booster lining
  • Portable, easy to use
  • 2 year warranty on heater
  • 115-volt household wiring
  • UPS or truck shipment
  • National Safety Code Certified/ETL
  • One-Year Parts Warranty



Optional Features

  • Folding Legs (instant set-up, no tools needed)
  • Production Package includes Large I.R. Heater Panel (18" x 24" 220-volts)
  • Cap Side-mounted I.R.panel (6" x 24")
  • 220 Volt Wiring
  • Crating
Price, Design & Specifications Subject to Change Without Notice. * Based on printing with 230 mesh, fast-cure Multi-Tech plastisol inks - produciton rates will vary based on factory, produciton techniques, print and garment. ** Amperage must be recalculated if incoming voltage is different.



Specifications

 1805-1201805-220
Estimated Max. Production 60* 144*
Overall Length 5' 5'
Overall Width 28" 28"
Belt Width 18" 18"
Overall Height (floor to top) 44" 44"
Heat Chamber Length 3' 3'
In-Feed 1' 1'
Out-Feed 1' 1'
Belt Height 34" 34"
Heat Panels 1 1
Max. Heater Wattage 1800 3000
Heater Size 18" x 18" 18" x 24"
AMPS: 120 or 230 volts, Single Phase, 3 wires + grnd 15 13
Est. Crated Weight - lbs 315 325
Est. Crate Size (W x L x H) 44" x 66" x 35" 44" x 66" x 35"

  Note: Control Box is located on the Right Side of the Dryer on the in-feed channel

Reasons To Buy

  • Compact and Portable Design
  • 120 Volt; Standard Plug-In Wiring (optional 220 volts available)
  • Variable Temperature Controller
  • Solid-State, Variable Belt Speed Controller
  • Total Insulation Package for Energy-Efficiency
  • Easy 4-Point Belt Tracking
